JC Red

Techincal parameters for JC Tubular - Red Series
Type Capacity (Ah) Product Overall Dimension L x W x H
JC Red Tubular - C20 Rating
JCRTT - 150L 150Ah 503 x 190 x 418
Note: Tolerance for weight, volume are +/- 5% and dimension is +/- 3mm. Specifications are subject to change without prior notice. The designs, images shown in the website is to provide outline information of the products only.
Battery Range Warranty Inverter Model Maximum Load Acceptable by Inverter 75% of Acceptable Load 50% of Acceptable Load
JCRTT - 150L 48 Months* 800 VA 640 Watts 1 hr & 45 mins 3 hrs
Note:
  • Light - 40 Watts (Approx), Fan - 70 Watts (Approx), LED TV - 55 Watts (Approx), LCD - 70 Watts (Approx), CRT or Plasma TV - 150 Watts (Approx).
  • Recommended charging current - 7 % to 8 % current of the rated battery Ah.
  • Tolerance for backup time are +/- 15%.
